Description

DC voltage: 200mV-2V-20V-200V-1000V, ± (0.5% 1dgt)
AC voltage: 200mV-2V-20V-200V-750V, ± (0.8% 3dgt)
DC current: 2mA-20mA-200mA-20A, ± (0.5% 1dgt)
AC current: 20mA-200mA-20A, ± (1.0% 3dgt)
---- Resistance: 200Ω-2KΩ-20KΩ-200KΩ-2MΩ-20MΩ-200MΩ, ± (0.8% 1dgt)
---- Capacitance: 20nF-200nF-2uF-20uF-200μF, ± (2.5% 3dgt)
Diode: Yes
Transistor: Yes
Buzzer function: Yes
Power supply: 6F22 type 9V battery
Large display value: 1999
Dimensions: about 190 × 90 × 30mm
